Hand free reader Character:

Electromagnetic radiation characteristics in the 2.45 GHz frequency band allow high data transmission rates and directional antenna beams. Tag detection is therefore very rapid and relatively insensitive to environmental interference. The Jutai tag is electro-magnetically inactive when outside of the reader’s range. It's state-of-the-art feature (registered patent) is its capacity to reflect incident microwaves - a tag receiving a 2.45 GHz carrier will echo this signal, modulated by its individual identification code, back to the reader. The reader receives and processes this signal, sending the data to a host system via a standard interface.

RFID reader Spec.
Anti-collision capacity:100pcs
Work frequency:2.4GHz~2.483GHz
Antenna polarization
Microwave COM check: CRC16 cyclic redundancy check
Reading range: 80M in maximum
Receiver sensitivity: -90dBm
Low power remind:relay output
Work supply :DC12V/1A
COM interface:RS485/wiegan
Baud：9600
Size:180mm*180mm*52mm
