Parking Barcode Ticket System Description:
Does your Shopping Mall have parking problems as follows:
- A capacity crowed at parking lot and often blocked, it is very difficult for customers to find a parking space?
- Often have to queue in the passageway, lead to customers very agitated, often get lots of complains?
- The queuing time is too long before the mall closed, often cause the charge dispute, even need to release vehicles for free to ease long lines and complaints?
- System vulnerability, results a lot of fraud and cash losing?
- System break down, cannot offer comfortable and quick service for customers?
Large Shopping Mall is a place where many shops and brands gathered, provide comfortable and quick parking lot experience is a very important aspect of improving service and increasing passenger flow volume of shops, and the spending power of motorists are stronger than other customers, so how to provide a high efficiency, security and stability parking lot is very important for the customer, and the parking lot is the place where gives them first impression and last impression, so choosing what kind of parking equipment for the operation of the whole Shopping Mall has the extremely important influence.



The Whole system include 3 parts:

1.Entrance parts.
2.Exit Parts
3.Charge Centre

Software Configuration
 Mifare IC card validator:
 Mifare IC card reader/writer
 Receipt Printer:
 Print method: direct thermal.
 Print speed: 25 RPM (6-inch per minute). Paper width: 60 mm.
 Cashier Drawer: 4 trays for bills, 8 trays for coins.
 Electrical: 110 or 220VAC, 50/60Hz.
 POS Application Software : Administration login : Username/Password login or authorization card required; Multiple authority levels can be applied for configuring differrent group of system functions.
 Parking rate configuration downloaded from the server:
--Time zone;
--week days,
--Holidays.
--Complimentary time
--Grace time.
 Fee calculation on lost tickets. Discount selection:
--Amount.
--Percentage.
--Hours.
 Mifare card reader (wall mount type) for season card (subscriber) system.
 Color TFT LCD touch screen for operator display.
 Operator shift report.

Parking automatic facilities with barcode ticket:


The System Parts:

Long Range Parking Reader JT PR-2S It is long range reader for parking control Read distance:1-15M adjust The card can't be copy.	Car parking management PM-900TEN is an Entry Terminal. It supports Mifare card as parking tickets It supports a barcode ticket as parking tickets.
IP Video Camera JTIV-200 IP Video Camera,can connect to software direction,not need to add another DVR Video Server.Save money.and control easy.	2.45GHz RFID tags JT ID-62 Intelligent tags Can't be copy,easy to use,hands free system. CR2032 battery,1pcs work lift >2years Also can used for remote control.Light Control.
Loop detector JTLD-100 Enhanced loop detector will trigger barrier gate to close automatically after vehicle complete passed through,Self-tuning range:20-2000UH	Traffic barrier gate JTBG-630 1.2s,3s,6s be selected; Arm 3-6m; The clutch on pendulum axis, barrier boom upped quickly by hand underPower status, rest automatically when power off.
Cashier Station PM-900TEN Cashier Station is a PC based POS computer in JUTAI parking system. It supports the barcode tickets and provides a manned payment service for a parking facility.	More Information: info@jutairfid.com

Barcode Ticket parking System datasheet download(If you can't open,pls contact our sales person,tks for follow Jutai):

1.JUTAI-barcode-ticket-system-installation	751K
2.JUTAI-barcode-ticket-system-introduction	799K
3.JUTAI-barcode-ticket-system	1.22M
